PDES-MINI – Pressurized Substance Application
Add to Wishlist
Remove from Wishlist
Pressurized Substance Application
- Remote control for all parameters
- Timer-based or TTL Triggered application
- Pressure control by analog voltage
- Pressure readout as analog voltage
- New housing with small footprint
- Direct placement near experiment
- Portable between setups
- Simplified installation
- See also here for the standard PDES 19″ system.
Models
| Model |
Pressure control |
Timer |
| PDES-MINI-RC-T: |
Remotely via analog signal, or 10-turn potentiomer |
Pushbutton timer |
| (0.1 … 9999.9 ms) |
| or TTL control |
| PDES-MINI-RC: |
Remotely via analog signal, or 10-turn potentiomer |
Timing controlled by TTL only |
| PDES-MINI-MAN-T: |
Manual pressure controller |
Pushbutton timer |
| (0.1 … 9999.9 ms) |
| or TTL control |
| PDES-MINI-MAN: |
Manual pressure controller |
Timing controlled by TTL only |
Technical Data
| Input pressure: |
5 bar max. |
| Output pressure: |
0.2 … 4 bar |
| Analog pressure control: |
0 … 8 V; scaling: 0.5 bar/V |
| Trigger input: |
5 V TTL signal |
| Pressure monitor output: |
0… 4 V; scaling 1 bar/V |
| Ejection times: |
Standard external valve: 20 ms and longer
microJECT valve: 2 ms and longer |
