2PK+ – Pipette Perfusion

Add to Wishlist Remove from Wishlist

2PK+ Patch Pipette Perfusion System

  • perfusion of patch pipettes during redording
  • ideal for second-messenger studies
  • optional rotating carousel for up to 6 solutions
  • can be used to control the HOLD pressure of PDES-DXH

About 2PK+

The 2PK+ increases the type and variety of experiments that can be performed because it enables the change of solution inside the pipette and in the whole-cell itself. The use of this kit should not increase electrical noise during recordings. The generator will control and measure pressure/vacuum to an accuracy of +/-0.2mmHg throughout the range of +/- 40mmHg. This precise control of pressure and vacuum helps prevent cell damage and enables experiments with limited electrical noise. It needs a minimum gas input of 15PSI/100kPa to perform properly.

In the whole-cell perfusion mode, positive pressure and our unique pressure vessel are used to force the perfusion solution into the recording pipette which then diffuses into the cell. The perfusion solution is sealed into the pressure vessel where it is forced by pressure through a quartz capillary and then into the pipette where it is deposited near the tip. Since positive pressure is being introduced, the negative pressure port on the pipette holder can be used to balance the pipette pressure. This allows the cell (after proper tuning of the vacuum/pressure generator) to experience no net change in pressure (i.e. it is neither pressurized nor are its contents sucked out). The simple streaming of solution within the pipette causes solution to flow out the tip and into the cell. Depending on cell size, flow rates, solution viscosity, and pipette size, cell perfusion times can vary from seconds to minutes.

In the patch perfusion mode, the vacuum port is used to suck the perfusion solution into the patch pipette through the quartz perfusion capillary. The vacuum is slowly increased to start the solution flow. Once perfusion starts, the vacuum is slowly decreased until a steady state of flow is reached. In this mode the pressure port may not be used.



Each 2PK+ system includes the following:

    • Pressure/vacuum generator
    • Perfusion pipette holder (specify amplifier used)
    • Perfusion pressure vessel
    • Quartz perfusion capillaries

Ordering

Part No. Description
ALA 2PK PLUS Whole-Cell / Patch Pipette Perfusion Kit: pressure/vacuum generator, pipette holder (specify amplifier), perfusion pressure vessel, and quartz capillaries
ALA 2PK 30GA 30 Gauge replacement needles – pack of 100
ALA 2PK RES Set of 3 extra 0.125mLreservoirs
ALA 2PK+PC Perfusion pressure cell (includes 3 reservoirs)
ALA 2PK+T Butane torch
ALA 2PK P/V 2PK+ Pressure/Vacuum Generator with output tubing
ALA MRC-6 Multi-Reservoir Carousel (includes 3 reservoirs)
ALA QT-100 20 pieces of 100μm ID x 4″ Quartz Glass (other ID sizes available)
PPH-2P-AXU Axon / Molecular Devices type straight pipette holder with Ag wire and 2 ports
PPH-2P-BNC BNC type straight pipette holder with Ag wire and 2 ports
PPH-______ Other / custom pipette holders available



Technical Data

Dimension 8″ W x 7.5″ L x 3.5″ H
Weight 18 oz.
Power (regulated) 9V DC 200mA
Input range 15PSI (100kPa) Min. / 50PSI (345 kPa) Max.
Output range +/- 40 mmHg
Accuracy +/- 0.2 mmHg
